ROG STRIX B450-E GAMING
1-11
Chapter 1
1.1.8 Internal connectors
1. AMD Serial ATA 6.0 Gb/s connectors (7-pin SATA6G_1-6)
TheseconnectorsconnecttoSerialATA6.0Gb/sharddiskdrivesviaSerialATA6.0
Gb/ssignalcables.
IfyouinstalledSerialATAharddiskdrives,youcancreateaRAID0,1,and10
congurationthroughtheonboardAMDB450chipset.
• Theseconnectorsaresetto[AHCI]bydefault.IfyouintendtocreateaSerialATA
RAIDsetusingtheseconnectors,settheSATAModeSelectionitemintheBIOSto
[RAID].
• BeforecreatingaRAIDset,refertotheRAID Configuration Guide.Youcan
downloadtheRAID Configuration GuidefromtheASUSwebsite.
