2-2
Chapter 2: Basic Installation
Chapter 2
CPU heatsink and fan assembly T
ype 1
2.1.2
Cooling system installation
Apply the Thermal Interface Material to the CPU
cooling system and CPU before you install the
cooling system, if necessary.
37
39
