Asus RS300-E10-PS4 - Installing M.2 (NGFF) Cards

Chapter 2: Hardware Information
2-20
2.5.5 Installing M.2 (NGFF) cards
To install an M.2 card:
1. Locate the M.2 connector (NGFF1) on the motherboard.
2. Remove the screw on the stand screw.
3. Prepare the M.2 card.
4. Align and insert the M.2 card into the M.2 connector (NGFF1).
5. Secure the M.2 card with the screw you removed in step 2.
• Please pay attention when removing the screw, the stand screw might be removed
together with it.
• Ensure that the M.2 card is positioned between the screw and the stand screw before
securing it.
Stand screw
Screw hole
Screw
NGFF1
