Asus RS500A-E6/PS4 - Page 111

ASUS RS500A-E6/PS4 6-7
5. After you have selected desired disks for the RAID set, press <Ctrl> + <Y> to
start building the RAID set.
FastBuild (tm) Utility (c) 2004-2010 Promise Technology, Inc.
[ LD Dene Menu ]
[ Keys Available ]
[
↑
] Up [
↓
] Down [PaUp/PaDn] Switch Page [Space] Change Option
[Ctrl+Y] Save [ESC] Exit
[ Drives Assignments ]
LD No LD Name
LD 1 Logical Drive 1
Stripe Block 128 KB
Gigabyte Boundary ON
Read Policy Read Cache
RAID Mode Drv
RAID 1 2
Initialization Fast
Write Policy WriteBack
Port:ID Drive Model Capabilities Capacity(GB) Assignment
01:01 HDTXXXXXXXXXXXX SATA 3G 250.05 Y
02:01 HDTXXXXXXXXXXXX SATA 3G 250.05 Y
03:01 HDTXXXXXXXXXXXX SATA 3G 250.05 N
04:01 HDTXXXXXXXXXXXX SATA 3G 250.05 N
Please Press Ctr-Y key to input the LD name
or press any key to exit.
If you do not input any LD name, the default
LD name will be used.
4. After you have selected the desired RAID mode, use the down arrow key to
select desired disks for the RAID set.
FastBuild (tm) Utility (c) 2004-2010 Promise Technology, Inc.
[ LD Dene Menu ]
[ Keys Available ]
[
↑
] Up [
↓
] Down [PaUp/PaDn] Switch Page [Space] Change Option
[Ctrl+Y] Save [ESC] Exit
[ Drives Assignments ]
LD No LD Name
LD 1 Logical Drive 1
Stripe Block 128 KB
Gigabyte Boundary ON
Read Policy Read Cache
RAID Mode Drv
RAID 1 1
Initialization Fast
Write Policy WriteBack
Port:ID Drive Model Capabilities Capacity(GB) Assignment
01:01 HDTXXXXXXXXXXXX SATA 3G 250.05 Y
02:01 HDTXXXXXXXXXXXX SATA 3G 250.05 N
03:01 HDTXXXXXXXXXXXX SATA 3G 250.05 N
04:01 HDTXXXXXXXXXXXX SATA 3G 250.05 N
