ASUS RS500A-E6/PS4 5-21
SR5650Conguration
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
Advanced
←→ Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
PCI Express Congurat
SR5650 Conguration
PCI Express Conguration
Hyper Transport Conguration
IOMMU [Disabled]
Primary Video Controller [Slot1-PIKE-PCI]
Debug Option
PCIExpressConguration
PCIE Slot 1/PIKE Slot Features
Select an item, and then press <Enter> to display its sub-items.
Gen2 High Speed Mode [Auto]
Conguration options: [Auto] [Disabled] [Software Initiated] [Advertised RC]
Link ASPM [Disabled]
Conguration options: [Disabled] [L0s] [L1] [L0s & L1] [L0s Downstream]
[L0s Downstream + L1]
Compliance Mode [Disabled]
Conguration options: [Disabled] [Enable]
Lane Reversal [Disabled]
Conguration options: [Disabled] [Enabled]
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
Advanced
PCI Express Conguration
PCIE Slot 1 Features
PIKE Slot Features
NB-SB Port Features
PCIE Slot 1 Core Setting
PIKE Slot Core Setting
SB Core Setting
←→ Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
