Enables/Disables Intel(R)
I/O Acceleration Technology
(I/OAT).
Intel(R) I/OAT [Disabled]
DCA Support [Enabled]
VGA Priority [Offboard]
TargetVGA VGA From CPU
0
Gen3 Equalization WA’s [Disabled]
IOH Resource Selection Type [Auto]
MMIOH Size [64G]
IOH 0 PCIe port Bifurcation Control
IOU1 - PCIe Port [x4x4]
Port 1A Link Speed [Gen2]
Port 1B Link Speed [Gen2]
IOU2 - PCIe Port [x16]
Port 2A Link Speed [Gen2]
IOU3 - PCIe Port [x8x8]
Port 3A Link Speed [Gen2]
Port 3C Link Speed [Gen2]
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
Intel(R) I/OAT [Disabled]
Allows to Enabled/Disabled Intel I/O accelaration technology.
Conguration options: [Disabled] [Enabled]
DCA Support [Enabled]
Allows to Enabled/Disabled direct cache access support.
Conguration options: [Disabled] [Enabled]
TargetVGA
VGA Priority [offboard]
Allows to decide priority between onboard and 1st offboard video device found.
Conguration options: [Onboard] [Offboard]
CPUIIOBridgeConguration
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
DIMM Information
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
CPU1 DIMM Information
Node 0 Ch0 Dimm A1 Present 1024 MB(DDR3)
Node 0 Ch0 Dimm A2 Not Present
Node 0 Ch0 Dimm A3 Not Present
Node 0 Ch1 Dimm B1 Not Present
Node 0 Ch1 Dimm B2 Not Present
Node 0 Ch0 Dimm B3 Not Present
Node 0 Ch2 Dimm C1 Not Present
Node 0 Ch2 Dimm C2 Not Present
Node 0 Ch0 Dimm C3 Not Present
Node 0 Ch3 Dimm D1 Not Present
Node 0 Ch0 Dimm D2 Not Present
Node 0 Ch3 Dimm D3 Not Present
CPU2 DIMM Information
