Support for PCH Compatibility
Revision ID(CRID)
functionality.
Name Patsburg
Stepping 05 (C0 Stepping)
SB Chipset Conguration
PCH Compatibility RID [Disabled]
SMBus Controller [Enabled]
SLP_S4 Assertion Stretch Enable [Enabled]
SLP_S4 Assertion Stretch Enable [4-5 Seconds]
Deep Sx [Disabled]
SCU devices [Enabled]
Onboard SAS Oprom [Enabled]
Onboard SATA RAID Oprom [Enabled]
High Precision Event Timer Conguration
High Precision Timer [Enabled]
Thermal Management [Disabled]
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
PCHConguration
PCH Compatibility RID [Disabled]
Support for PCH compatibility.
Conguration options: [Disabled] [Enabled]
SMBus Controller [Enabled]
Allows to enabled/disabled SMBus controller.
Conguration options: [Disabled] [Enabled]
SLP_S4 Assertion Stretch Enable [Enabled]
Allows to enabled/disabled SLP_S4# assertion stretch.
Conguration options: [Disabled] [Enabled]
SLP_S4 Assertion Stretch Enable [4-5 Seconds]
Select a minimum assertion width of the SLP_S4# signal.
Conguration options: [1-2 Seconds] [2-3 Seconds] [3-4 Seconds] [4-5 Seconds]
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
PORT 3A Link Speed [Gen2]
Select target link speed Gen1, Gen2 or Gen3.
Conguration options: [Gen1] [Gen2] [Gen3]
PORT 3C Link Speed [Gen2]
Select target link speed Gen1, Gen2 or Gen3.
Conguration options: [Gen1] [Gen2] [Gen3]
IOH1 PCIe port Bifurcation Control
This item appears only when you installed CPU2 on the motherboard.
