Chapter 1: Product Introduction
1-2
If any of the above items is damaged or missing, contact your retailer.
1.1 System package contents
Check your system package for the following items.
Model Name RS720Q-E9-RS24-S
Chassis ASUS 2U Rackmount Chassis
Motherboard ASUS Z11PH-D12 Server Board
Component
2 x 1600/2200W Power Supply
4 x PCIe Riser Card (RE16L-R21L)
2 x Front Panel Board (LED Board, FPB-R2H-A)
2 x Power Supply Distribution Board (PDB-R2H-A)
1 x Power Connection Board (PSB-R2H-A)
1 x Backplane Board (BP8LE16LX12G-25-R2H-A)
2 x Midplane Board (MP4LE16LX12G-R2H-A)
2 x Back plane Fans (40mm x 28mm)
4 x System Fans (80mm x 38mm)
24 x Hot-swap 2.5” Storage Bays
Accessories
1 x ASUS RS720Q-E9-RS24-S Series Support DVD (includes User Guide)
8 x CPU Heatsinks
1 x Bag of Screws
2 x AC Power Cables
1 x Friction Rail Kit
8 x LGA3647-P0 NRW-NF-CPU Carrier (Barebone)
4 x LGA3647-P0 NRW-F-CPU Carrier (Barebone)
