Chapter 1: Product Introduction
1-6
Refer to the
Front panel LEDs
section for the LED descriptions.
Turn off the system power and detach the power supply before removing or replacing any
system component.
Asset tag
The Asset tag is a small polyester lm located to the right side of the server’s front right panel.
It provides information about the server such as asset barcode or serial number and is useful
in asset tracking and inventory management.
1.4 Front panel features
Front panel
Node 2
The barebone server displays easily accessible features such as the power and reset
buttons, LED indicators, and optical drive.
Front panel
Node 1
Asset tag
Front panel
Node 4
Front panel
Node 3
Node 1
(Bay 1-6)
Node 2
(Bay 7-12)
Node 3
(Bay 13-18)
Node 4
(Bay 19-24)
