RT-N14UChapter 4: Using the Utilities
Device Discovery
Device Discovery is an ASUS WLAN utility that detects an ASUS
wireless router device, and enables you to configure the device.
To launch the Device Discovery utility:
• From your computer’s desktop, click
Start > All Programs > ASUS Utility > RT-N14U Wireless
Router > Device Discovery.
When you set the router to Access Point mode, you need to use
Device Discovery to get the router’s IP address.
4
Using the utilities

Asus RT-N14U Specifications

General

VPN support	IPSec Pass-Throuth\\r PPTP Pass-Through\\r L2TP Pass-Through
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
USB version	2.0
Input current	1 A
Rack mounting	-
Frequency band	2.4 GHz
Frequency range	2.4 - 2.4835 GHz
USB ports quantity	1
Minimum system requirements	Windows® 8 , 32bit/64bit\\r Windows® 7 , 32bit/64bit\\r Windows® Vista , 32bit/64bit\\r Windows® XP , 32bit/64bit
WLAN data transfer rates supported	1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54, 300 Mbit/s
Ethernet LAN (RJ-45) ports	5
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK, WPS
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
LED indicators	LAN, Power, USB, WLAN

Weight and Dimensions

Depth	145 mm
Width	187 mm
Height	77 mm
Weight	260 g
