ASUS TROOPER B85
1-3
1.3 Central Processing Unit (CPU)
ThismotherboardcomeswithasurfacemountLGA1150socketdesignedforNew4th
GenerationIntel
®
Core™i7/i5/i3,Pentium
®
andCeleron
®
processors.
1.2.4 Layout contents
UnplugallpowercablesbeforeinstallingtheCPU.
• Uponpurchaseofthemotherboard,ensurethatthePnPcapisonthesocketand
thesocketcontactsarenotbent.ContactyourretailerimmediatelyifthePnPcap
ismissing,orifyouseeanydamagetothePnPcap/socketcontacts/motherboard
components.ASUSwillshoulderthecostofrepaironlyifthedamageisshipment/
transit-related.
• Keepthecapafterinstallingthemotherboard.ASUSwillprocessReturnMerchandise
Authorization(RMA)requestsonlyifthemotherboardcomeswiththecaponthe
LGA1150socket.
• Theproductwarrantydoesnotcoverdamagetothesocketcontactsresultingfrom
incorrectCPUinstallation/removal,ormisplacement/loss/incorrectremovalofthePnP
cap.
Connectors/Jumpers/Slots/LED Page
1. ATXpowerconnectors(8-pinEATX12V,24-pinEATXPWR) 1-15
2. CPUandchassisfanconnectors(4-pinCPU_FAN,4-pinCHA_FAN) 1-14
3. Intel
®
LGA1150CPUsocket 1-3
4. DDR3DIMMslots 1-6
5. Intel
®
B85SerialATA6.0Gb/sconnector(brown) 1-16
6. Intel
®
B85SerialATA3.0Gb/sconnector(black) 1-16
7. Systempanelconnector(20-8pinF_PANEL) 1-17
8. ClearRTCRAM(2-pinCLRTC) 1-10
9. Chassisintrusionconnector(4-1pinCHASSIS) 1-19
10. USB3.0connector(20-1pinUSB3_1314) 1-17
11. USB2.0connectors(10-1pinUSB910,USB1112) 1-14
12. TPMheader(20-1pinTPM) 1-18
13. Digitalaudioconnector(4-1pinSPDIF_OUT) 1-13
14. Frontpanelaudioconnector(10-1pinAAFP) 1-13
15. Serialportconnectors(10-1pinCOM) 1-18
