Asus Trooper B85 - Serial ATA 3.0 Gb;s Connectors; Serial ATA 6.0 Gb;s Connectors

1-16
Chapter 1: Product introduction
6. Intel
®
B85SerialATA3.0Gb/sconnectors(7-pinSATA3G1~2[beige])
TheseconnectorsconnecttoSerialATA3.0Gb/sharddiskdrivesviaSerialATA3.0
Gb/ssignalcables.
7. Intel
®
B85SerialATA6.0Gb/sconnectors(7-pinSATA6G_1~4[black])
TheseconnectorsconnecttoSerialATA6.0Gb/sharddiskdrivesviaSerialATA6.0
Gb/ssignalcables.
Whenusinghot-plugandNCQ,settheSATA Mode SelectionitemintheBIOSto[AHCI].
Whenusinghot-plugandNCQ,settheSATAModeSelectionitemintheBIOSto[AHCI].
