12 ASUS TX97 User’s Manual
III. INSTALLATION
Map of the ASUS TX97 Motherboard
(Map of Board)
III. INSTALLATION
Serial Ports
ATX Power Switch
Clock Freq
FS1 FS0 FS2
R
IDE LED
Panel Connectors
Infrared
Vcore Voltage
Freq. Ratio
CPU ZIF Socket 7
RTC Clear
Boot
Block
Write
Chasis Open
Alarm
Intel
PIIX4
PCIset
Keyboard BIOS
Floppy Drives Secondary IDE Primary IDE
Multi-I/O (En/Dis)
Key-
board
Parallel (Printer) Port
Board Power Input
P8
P9
DIMM Socket 3 DIMM Socket 2 DIMM Socket 1
ISA Slot 3 ISA Slot 2 ISA Slot 1 ISA Slot 4
PCI Slot 4 PCI Slot 3
PCI Slot 2
PCI Slot 1
MediaBus Extension
Super Multi-I/O
COM 2
COM 1
PS/2 Mouse,
USB, IrDA
Flash BIOS
CR2032 3Volts
Lithium Cell
(BIOS Power)
512KB Pipelined Burst L2 Cache
Chassis Fan
Hardware Monitor
VID1 VID0 VID2
BF1 BF0
Heat
Sensor
CPU Fan
Power Fan
Intel
430TX
PCIset
Switching Voltage Regulators
