2.2 Motherboard rear and audio connections
2.2.1 Rear I/O connection
* and **: Refer to the tables on the next page for LAN port LEDs, and audio port denitions.
Rear panel connectors
1. PS/2 keyboard / mouse combo
port
6. HDMI port
2. Optical S/PDIF Out port 7. DVI-D port
3. Video Graphics Adapter (VGA)
port
8. Intel USB 3.0 ports 3-4, support ASUS
USB 3.0 Boost
4. Realtek
®
LAN (RJ-45) port*
9. Intel USB 3.0 ports 5-6, support ASUS
USB 3.0 Boost. Bottom port supports USB
BIOS Flashback and USB Charger+
5. USB 2.0 ports 7 and 8 10. Audio I/O ports**
