Z87M-PLUS specications summary
CPU LGA1150 socket for Intel
®
4th Generation Core™ i7 / Core™ i5 /
Core™ i3, Pentium
®
, and Celeron
®
processors
Supports 22nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to
www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
Z87 Express Chipset
Memory 4 x DIMM, max. 32GB, DDR3 2800 (O.C.) / 2666 (O.C.) / 2600 (O.C.) /
2400 (O.C.) / 2200 (O.C.) / 2133 (O.C.) / 2000 (O.C.) / 1866 (O.C.) /
1600 / 1333 MHz, non-ECC, un-buffered memory*
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Hyper DIMM support is subject to the physical characteristics of individual
CPUs. Please refer to Memory QVL (Qualied Vendors List) for details.
** Refer to
www.asus.com or this user manual for the Memory QVL (Qualied
Vendors List).
Expansion slots 1 x PCI Express 3.0/2.0 x16 slot [yellow] (at x16 mode)
1 x PCI Express 2.0 x16 slot [dark brown] (run at x4 mode, compatible
with PCIe x1 and x4 devices)
2 x PCI Express 2.0 x1 slots
* The PCIe x16_2 slot shares bandwidth with PCIe x1_2 slot. The default
setting is x2 mode. Go to the BIOS setup to change the settings.
VGA Integrated Graphics Processor - Intel
®
HD Graphics support
Multi-VGA output support: HDMI/DVI-D/RGB port
Supports HDMI with max. resolution of 4096 x 2160 @24Hz and 2560
x 1600 @60Hz
Supports DVI-D with max. resolution of 1920 x 1200 @60Hz
Supports RGB with max. resolution of 1920 x 1200 @60Hz
Supports Intel
®
InTru™ 3D, Intel
®
Quick Sync Video, Intel
®
Clear Video
HD Technology, and Intel
®
Insider™
Supports up to three displays simultaneously
Maximum shared memory 1024MB
Multi-GPU support Supports AMD
®
Quad-GPU CrossFireX™ Technology
Storage
Intel
®
Z87 Express Chipset
- 6 x SATA 6.0 Gb/s ports (yellow) with RAID 0, 1, 5, 10 and Intel
®
Rapid Start Technology 12 support
- Supports Intel
®
Dynamic Storage Accelerator, Intel
®
Smart
Response Technology, Intel
®
Rapid Start Technology, and Intel
®
Smart Connect Technology*
* These functions will work depending on the CPU installed.
LAN Realtek
®
8111GR Gigabit LAN controller
Audio Realtek
®
ALC887 8-channel high denition audio CODEC
- Supports jack-detection, multi-streaming, and front panel jack-
retasking
- Optical S/PDIF out ports at back I/O
(continued on the next page)
