1.8 Onboard LEDs
1. Standby Power LED (SB_PWR)
ThemotherboardcomeswithastandbypowerLEDthatlightsuptoindicatethatthe
systemisON,insleepmode,orinsoft-offmode.Thisisareminderthatyoushould
shutdownthesystemandunplugthepowercablebeforeremovingorplugginginany
motherboardcomponent.TheillustrationbelowshowsthelocationoftheonboardLED.
SB_PWR
ON
Standby Power Powered Off
OFF
Z97-E/USB 3.1
Z97-E/USB 3.1 Standby power LED
