Asus Z97-E/USB3.1 - Serial Port Configuration

SPDIF Out Type [SPDIF]
[SPDIF] Sets to an SPDIF audio output.
[HDMI] Sets to an HDMI audio output.
Depop [Enabled]
Conguration options: [Disabled] [Enabled]
Audio Shielding LED [Auto]
[Auto] The LED control depends on the conguration of the ErP Ready item. Set
this item to [Auto] and the ErP Ready item to [Disabled] to keep the LED
on.
[Disabled] Turn off the LED.
ASM1142 Bandwidth [X2 mode]
[X2 mode] ASM1142 runs at X2 mode for high performance support. PCIe X1_2 will
be disabled.
[X1 mode] ASM1142 runs at X1 mode with all slots enabled.
Asmedia USB 3.1 controller [Enabled]
[Enabled] Enables the Asmedia USB 3.1 controller.
[Disabled] Disables the controller.
The following two items appear only when you set the Asmedia USB 3.1 controller item to
[Enabled].
USB 3.1_1 [Enabled]
[Enabled] Enables the USB 3.1_1 port.
[Disabled] Disables the port.
USB 3.1_2 [Enabled]
[Enabled] Enables the USB 3.1_2 port.
[Disabled] Disables the port.
Intel LAN Controller [Enabled]
[Enabled] Enables the Intel LAN controller.
[Disabled] Disables the controller.
Intel LAN PXE Option ROM [Disabled]
This item appears only when you set the previous item to [Enabled] and allows you to enable
or disable the PXE OptionRom of the Intel LAN controller. Conguration options: [Enabled]
[Disabled]
Serial Port Configuration
The sub‑items in this menu allow you to set the serial port conguration.
Serial Port [Enabled]
Allows you to enable or disable the serial port (COM).Conguration options: [Enabled]
[Disabled]
2‑38 Chapter 2: Getting started
