There are many instruments
involved in the safe operation of
your machine. Make sure to
learn the location, and function
of each of these items prior to
operating your machine.
Instrument Display
The instrument display has been
configured for visibility and
ergonomic function.
The display includes:
A. Engine Temperature Gauge
B. Oil Pressure Gauge
C. Fuel Gauge
D. Hydraulic Oil Temp. Gauge
E. Voltmeter
F. Tachometer
G. High Range Indicator
H. Glow Plug Operation Indicator
I. Low Range Indicator
J. Parking Brake Indicator
K. Hour Meter
Note: The locations of items A-U
within the operator enclosure
may differ from the illustrations.
However, they are present and
easily identified by label, form,
or by icons present on the com-
ponents.
The glow plug operation light
should illuminate only when the
ignition switch is turned to the
pre-heat position.
Pay close attention to the dis-
play during operation to ensure
that all systems are functioning
properly.
CONTROLS
Instrument Display
15
A
B C
D E
F
I J
G H
K
