ASV PT70 - Page 47

Engine Oil Specifications
Use ASV 10W-30 Heavy Duty
Engine Oil for most conditions.
In the event of an alternate
working environment, the chart
above may be used as a guide
to oil viscosity grades.
You may also use a quality
engine oil substitute meeting the
following minimum specification:
• API CH-4 multigrade engine
oil.
Oil Level Check
To check the oil level:
1. Park the machine on level
ground.
2. Open the hood to gain
access to the engine com-
partment.
3. Locate and remove the
engine oil dipstick (A) from
its tube.
4. Wipe the dipstick with a
clean shop cloth and re-
insert it into the tube until it
comes to rest in its seated
position.
5. Remove the dipstick
once again and inspect the
end for oil on the level indi-
cator.
6. Oil should be present on
the dipstick up to, but
not over the upper (full)
level indicator notch. If
the level is correct, re-
install the dipstick and
then close and latch the
hood to complete the
procedure.
7. If the level is low, add the
proper grade and viscosity
engine oil and re-check as
necessary until the proper
level has been achieved.
Then re-install the dipstick
and filler cap and close and
latch the hood to complete
the procedure.
47
Low
Full
A
MAINTENANCE
Engine
