5 Mounting the boiler
Install the boiler in a well-ventilated boiler room in accordance to the actual
local regulations BS5440-2:2000.
The installation location of the CH-boiler(s) has to be, and remain, frost-free. The boiler
casing is splash water tight (IPX4D) and is suitable to be installed in e.g. a bathroom.
It is NOT necessary to have a purpose provided air vent in the room or internal space in
which the boiler is installed. Neither is it necessary to ventilate a cupboard or compartment
in which the boiler is installed, due to the extremely low surface temperature of the
boiler casing during operation. Therefore the requirements of BS 6798, Clause 12, and
BS5440:2 may be disregarded.
The boiler can be mounted practically to any wall with the suspension bracket and the
enclosed xing equipment. The wall must be at and of sufcient strength in order to be
able to carry the boiler weight with its water content.
Above the boiler there must be at least 250 mm working space in order to be able to t a
coaxial ue system or a twin supply. On the left side of the boiler at least 50 mm and on
the right side 10 mm must be reserved to allow tting or removing of casing. The location
of the boiler can be determined by using the template.
Before hanging up the boiler remove the cover of the boiler rst. The cover is also the
air cabinet and is attached to the rear wall with four quick fasteners (A, B, C and D) (see
gure 5.a).
Secure the quick fasteners with the screws (A, B, C and D) at the back of the
cover.
Lift the boiler only by the boilers rear wall.
Figure 5.a
Lifting and carrying precautions:
- Lift only a manageable weight, or ask for help.
- When lifting the boiler, bend the knees, and keep the back straight and feet
apart.
- Do not lift and twist at the same time.
- Lift and carry the boiler close to the body.
- Wear protective clothing and gloves to protect from any sharp edges.
