Atag CS4574M User Manual

EN 55
• Disconnect the appliance from the power supply by removing the
plug from the socket or by switching off the circuit breaker in the
fuse box.
• Please note: the light bulb can be very hot! Use protection to
remove the bulb.
1. Remove the four screws from the cover panel. Remove the cover
panel, the glass and the sealing ring.
2. Remove the faulty halogen lamp and replace it with a new one.
3. Replace the cover panel, the glass and the sealing ring.
Attention: The sealing ring needs to fit perfectly in the oven wall
recess.
Removing the oven door
Keep your fingers away from the hinges of the oven door. The hinges
are spring loaded and can cause injury if they spring back.
Make sure that the hinge latches are applied correctly to lock the
hinges.
Remove the oven door.
1. Open the door to the fully open position.
2. Lift both hinge latches (A) and pull them towards the oven door (B).
The hinges will be locked in the 45° position.
3. Gently close the door until it reaches a 45° angle.
CLEANING

Atag CS4574M Specifications

General

Connected load	3400 W
Energy consumption (conventional)	0.82 kWh
Energy consumption (forced convection)	0.62 kWh
Oven size	Medium
Oven type	Electric
Cleaning type	Steam
Number of ovens	1
Convection cooking	Yes
Oven thermostat range	40 - 230 °C
Total oven(s) interior capacity	51 L
Control type	Touch
Display type	TFT
Product color	Black
Appliance placement	Built-in
Timer type	Digital

Weight and Dimensions

Depth	547 mm
Width	598 mm
Height	456 mm
Installation compartment depth	550 mm
Installation compartment width	560 mm
Installation compartment height	460 mm
