Electrical connection
For the connection, use an approved cable, in accordance with the
regulations. The cable casing should be of rubber.
There is a label on the underside of the appliance with the wiring
diagrams. The connection terminals are accessible once you have opened
the junction box on the underneath. The junction box cover can be
opened with a screwdriver.
If you want to make a fixed connection, make sure that a multi-polar
switch with a contact separation of at least 3 mm is fitted in the supply
line.
Power setting table
Type of hob
HL62..E
Cooklight
x
Electrical connection
230 V - 50 Hz
x
Power of element
Front left
2200 W / 750 W
Rear left
1200 W
Rear right
1800 W
Front right
1200 W
INSTALLATION GUIDE build in HL62..E
75
