Atag i28C Technical Guide

AB: iS System boiler
A: DHW Cylinder
B: Heating system
B
A
A
AB
AB
B
Terminal block LV iC-Range
ATAG Outdoor sensor 1kOhm*
n.a. = not applicable
ATAG Zone connection
OpenTherm or ON/OFF thermostat
n.a. = not applicable
DHW sensor T3
External safety contact
terminal block
PE
N
PE
L
N
L’
230V out
230V Control
PE
N
L
230V in
N
L
230V out
DO NOT CONNECT 230 VOLT
* Mounting on north – north/east facade of the house. Prevent outside influences such as snow, ventilation air or chimney heat.
230V live output
to pump
E
N
L
E
L
N
SwL
230V out
230V Control
E
N
L
230V in
N
L
230V out
230V control terminal block iC-Range
N: Neutral
L: Live
E: Earth
N: Neutral
L: Live
E: Earth
L: Live
N: Neutral
SwL: Switched live 230V live input only!
E: Earth pump
N: Neutral pump
L: Live pump
230V live output
230V out
230V in LNE
Cylinder sensor ATAG outdoor
sensor (optional)
ATAG ONE
ZONE
controller
DO NOT CONNECT 230 VOLT
53
