EN 10
YOUR OVEN
Navigation
active area
stop key confirm keyfunction knob selection knobnavigation keys
By turning the function knob away from the 0-position, the icon of the
chosen main function is lit. The display will show the icon and name
of the activated function for about 1,5 seconds. Next you will see the
chosen main function and sub-function at the top of the display in the
feedback bar. Also the function settings mode will become active (grey
background). In this activated area you can select your settings using
the selection knob.
180
°C
STEAM l STEAM 14:30
Within every menu the navigation is as follows:
• Use the navigation keys or press the selection knob to move the
active area (grey background).
• The setting in the active area can be changed by turning the
selection knob (left = decrease, right = increase). The setting will be
saved automaticallly.
• When all elements in the screen are set, then confirm these settings
by pressing the confirm key (this key will start blinking when it is
possible to start the program).
• Press the stop key to go one step back in the menu.

Atag SX4511D Specifications

General

Oven size	Medium
Oven type	Electric
Number of ovens	1
Total oven power	- W
Microwave cooking	-
Number of shelves	1 shelves
Convection cooking	Yes
Oven thermostat range	35 - 100 °C
Auto programs quantity	96
Number of shelf positions	4
Total oven(s) interior capacity	51 L
Maximum temperature (conventional)	100 °C
Door hinge	down
Control type	Rotary, Touch
Display type	TFT
Door material	Glass
Product color	Black, Stainless steel
Control position	Front
Appliance placement	Built-in
Water tank capacity	1.5 L
Number of glass door panels	3
Clock type	Electronic
Timer type	Digital
Energy consumption (conventional)	- kWh

Weight and Dimensions

Depth	547 mm
Width	597 mm
Height	458 mm
Installation compartment depth	550 mm
Installation compartment width	568 mm
Installation compartment height	450 mm
