Atag SX4511D User Manual

EN 37
Removing the oven door
Keep your fingers away from the hinges of the oven door. The hinges
are spring loaded and can cause injury if they spring back.
Make sure that the hinge latches are applied correctly to lock the
hinges.
Remove the oven door.
1. Open the door to the fully open position.
2. Lift both hinge latches (A) and pull them towards the oven door (B).
The hinges will be locked in the 45° position.
3. Gently close the door until it reaches a 45° angle.
4. Remove the door by lifting and tilting it towards the oven (C). The
hinges need to come out of the slots in the oven.
B
A
C
Install the oven door.
1. Hold the door at an angle of approximately 45° in front of the oven.
2. Insert the hinges into the slots and make sure they are both
positioned correctly.
3. Open the door to the fully open position.
4. Lift both hinge latches and move them towards the oven.
5. Gently close the oven door and make sure that it closes correctly.
If the door does not open or close correctly, then make sure that the
hinges are positioned correctly in their slots.
CLEANING

Atag SX4511D Specifications

General

Oven size	Medium
Oven type	Electric
Number of ovens	1
Total oven power	- W
Microwave cooking	-
Number of shelves	1 shelves
Convection cooking	Yes
Oven thermostat range	35 - 100 °C
Auto programs quantity	96
Number of shelf positions	4
Total oven(s) interior capacity	51 L
Maximum temperature (conventional)	100 °C
Door hinge	down
Control type	Rotary, Touch
Display type	TFT
Door material	Glass
Product color	Black, Stainless steel
Control position	Front
Appliance placement	Built-in
Water tank capacity	1.5 L
Number of glass door panels	3
Clock type	Electronic
Timer type	Digital
Energy consumption (conventional)	- kWh

Weight and Dimensions

Depth	547 mm
Width	597 mm
Height	458 mm
Installation compartment depth	550 mm
Installation compartment width	568 mm
Installation compartment height	450 mm
