45
15 Specifications
Product name VISCO VISCO-895
Cat. No. 6800 6820
Measurement Scales Viscosity・Temperature・Torque%
Display Items Viscosity・Temperature・Torque%・Speed・Spindle and beaker combination
Measurement Range Viscosity： A1 50 to 200,000mPa・s / 50 to 200,000cP
A2 100 to 600,000mPa・s / 100 to 600,000cP
A3 500 to 2,000,000mPa・s / 500 to 2,000,000cP
Torque： 0.0 to 100.0％ (recommended torque: 10.0 to 100.0％)
Temperature： 0.0 to 100.0℃/32.0 to 212.0°F
Resolution Viscosity： lower than 100mPa・s 0.01mPa・s
100mPa・s or higher lower than 10,000mPa・s 0.1mPa・s
10,000mPa・s or higher 1mPa・s
Torque： Lower than 10% 0.01％
10% or higher 0.1％
Temperature： 0.1℃/0.1°F
Measurement Accuracy
Viscosity: ±1% of Maximum Viscosity
(Refer to the "Maximum Measurement Values Guideline Chart," from p.42)
Temperature: ±0.2℃/±0.4°F
Speed 0.5 to 250rpm
Number of Speeds: 20
Language Japanese / English
Sample Temperature
Range
10.0 to 40.0℃ / 50.0 to 104.0°F
Environmental
Conditions
• Use the instrument where the temperature is between 10 to 40℃
• Use the instrument at an altitude below 2,000m (above sea level).
• Use the instrument under the condition where humidity is 80% at 31℃
or lower, falling linearly to 50% at 40℃.
Computer Output Output: USB Mini-B - PC
Power Supply LR6 / AA alkaline batteries (x4)
AC adapter input: AC100 to 240V. 50/60Hz, 0.3A
output: 9V, 0.5A.
Battery Life ( Approx.) Approx. 7 hours (continuous operation at 60rpm)
Material Main unit: SUS316L, aluminium
Legs: SUS304
Stand: SUS304
Stand screw: SUS303
Main unit: aluminium
Legs: aluminium
Stand: aluminium
Stand screw: aluminium
Dimensions and Weight Main unit： 120(W)ｘ120(D)ｘ
200.6(H)mm
1.2kg (excluding
batteries, spindles
and temperature
sensor)
Stand+screw: 0.5kg
Small volume beaker attachment:0.1kg
Main unit： 120(W)ｘ120(D)ｘ
200.6(H)mm
0.895kg (excluding
and temperature
sensor)
Stand+screw: 0.27kg
Small volume beaker attachment: 0.1kg
