Battery Installation
NOTE: Line 2 will not work without AC power. Make sure the power
cord is connected to the phone and plugged into an electrical outlet.
Before using the telephone,you should install 4 AA batteries (not
included). In case of a power failure,you will only be able to make or
answer calls on Line 1. No other features will work,including Line 2.
When battery power is low,LOW BATT flashes on the display to alert you.
Replace batteries promptly.
CAUTION: Always disconnect all cords and remove base before
installing new batteries.
1 Turn the telephone upside down.
2 Remove the base (Figure 1).
Place your thumbs in the two openings at the large end of the
base. Push down with your thumbs,and lift the base up and away
from the phone.
3 Open the battery compartment door (Figure 2).
Press on the tabs and swing the door open.
4 Install 4 new AA batteries (Figure 3).
5 Close the battery compartment door.
INSTALLATION
4
Figure 1 Figure 2 Figure 3
