AT&T CL84102 - Review the Caller ID History

Caller ID
62
Caller ID operation
Review the caller ID history
Review the caller ID history to find out who called, to return
the call, or to copy the caller’s name and number into your
directory. Caller ID log empty appears if there are no records
in the caller ID log.
Using a cordless handset or the telephone base:
1. When the handset or the telephone base is in idle mode,
press qCID to review the caller ID history in reverse
chronological order starting with the most recent call.
-OR-
Review the caller ID history by pressing MENU/SELECT.
Press qCID or pDIR to scroll to >Caller ID log, then press
MENU/SELECT twice to select >Review.
2. Press qCID or pDIR to scroll through the list.
3. Press OFF/CANCEL on the handset or CANCEL on
the telephone base to exit the caller ID history.
You hear a double beep when the list reaches the
beginning or end of the caller ID log.
NOTE: Only one handset or the telephone base can review the
caller ID history at a time. If another device tries to enter the
directory or caller ID history, it shows Not available at this time.
HANDSET 1
6 Missed calls
NEW
10/15
10:01
AM
Directory
>Caller ID log
p
q
10:01
PM
10/15
MSG #
1
NEW
BASE
6 Missed calls
NEW
10:21
PM
CHRISTINE SMITH SMITH
888-883-2445
p
q
Caller’s name
Caller’s number
Appears if it is a
new or missed call.
Date of call
Time of call
10/15
Directory
>Caller ID log
p
q
AM
NEW
10/15
10:21
PM
10/15
NEW
CHRISTINE SMITH SMITH
888-883-2445
Date of call
Caller’s name
Caller’s number
Appears if it is a
new or missed call.
Time of call
p
q
