8
Getting started
Battery installation
Install the battery as shown below. After installing the battery,
you may be able to make and receive short calls. For optimal
performance, charge the headset battery for at least 6 hours
before use. When the headset is not in use, recharge the
headset by returning it to the headset base.
If the battery compartment cover is
attached, press on both sides of the
cover and lift it up and off.
Insert the battery into the battery
compartment with the label
THIS SIDE UP facing up.
Push the battery plug into the
connector inside the compartment
according to the color-coded label
Place the wires neatly inside
the compartment.
Insert the tab on the bottom of the
battery compartment cover into the
battery compartment.
Press down gently on the battery
compartment cover until it snaps
into place.
NOTE: Remove the ear hook from the headset (see page 24) before
battery replacement.
1.
2.
3.
4.
5.
4
2
3
1
