KT1 series chillers – Installation and Operation manual
Issue 3.2 14
6.0 Dimensions and performance
Kt1
Cooling Capacity
At 20°C set point and 20°C ambient
1000 Watts 50Hz
1200 Watts 60Hz
Dimensions H x W x D
490 x 370 x 560 mm
Weight
60 Kg
Temperature range
4°C - 35°C
Pumps available
P5, P10, P17
LED temperature display
0.1°C resolution standard.
Temperature control
Microprocessor P.I.D.
Pressure gauge
Standard
Fluid connections
3/8” and ½” barb supplied
Custom connections available
Temperature stability, under stable
conditions
0.1°C
Power requirements
7 Amps, 230V 50Hz
7 Amps, 208V 60Hz
7 Amps, 220V 60Hz
Warranty
2 years parts, 1 year labour
