Attach the heater to the wall bracket by aiming the 4 hooks on the bracket into the
corresponding holes on the back of the heater. Insert the bottom two hooks first and
then slide the top 2 hooks into position.
The upper section of the wall bracket incorporates a locking tag which should be
inserted into the hole on the back of the heater and tightened after the heater is
mounted on the wall. See Figure 2
NOTES
Prior to drilling the wall, ensure there are no cables or pipes within the wall
and ensure that the mounting screws are fixed firmly to guarantee that the
heater is safely mounted to the wall.
