ATC PH1000T User Manual

ATC ELECTRICAL & MECHANICAL
ATC House,
Broomhill Drive, Tallaght, D24 EF99
IRELAND
tel +353 1 4625111
fax +353 1 4520887
www.atc.ie sales@atc.ie
3. WALL MOUNTING INSTRUCTIONS
Remove the heater from the packaging and then disconnect the wall bracket from the
back of the heater.
Mark the wall according to the dimensions given in Figure 1 below for the heater of
your correct size.
Drill the wall and insert the plastic wall anchors into the holes. Mount the wall bracket
using the screws provided
Hook
Hook
Hook
Figure 1

ATC PH1000T Specifications

General

Brand	ATC
Model	PH1000T
Category	Heater
Language	English
