CS1308 / CS1316 User Manual
42
Preparation
To prepare for the firmware upgrade, do the following:
1. Use the Firmware Upgrade Cable provided with this unit to connect a COM
port on your computer to the Firmware Upgrade Port of your switch.
2. Shut down all the computers on the KVM installation.
3. From your KVM switch console, login to the OSD as the administrator
(see p. 19) and select the F4 ADM function.
4. Scroll down to FIRMWARE UPGRADE. Press [Enter], then press [Y] to
invoke Firmware Upgrade mode (see p. 27.)

ATEN CS1316 Specifications

General

Number of Ports	16
Dimensions	43.8 x 25.7 x 4.4 cm
Computer Connections	16
Ports	16
Operating Temperature	0 to 50°C
Storage Temperature	-20 to 60°C
Humidity	0 to 80% RH
Console Ports	1 x SPHD-18 Female (Yellow)
