CONFIGURATION FILES
Configuration files to use for the configuration of the master instrument.
Profibus hardware and software compatibilities
The table below gives the configuration file to use according to the hardware reference of the Profibus
internal board of your ATEQ device (Hilscher hardware reference).
Device
software
Fieldbus
Software
Hilscher
Firmware
Config Files
Hilscher Hardware
Ref
≥ 1.324
> 2.104
2.7.2
HIL_7501.GSD (09/03/2000)
COMX 100
In all cases, use the HIL_7501.GSD configuration file and the COM_DPS module name, even if the
COMX 100XXDP/DPS module is used.
