Chapter 4 – Functions of the instrument
UM-23100B-U User manual ATEQ F CLASS Page 58/90
2.3.5. 1) Example of parameter print frame
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
V e r s i o n 0 1 . 1 1 h
0 2 / 1 0 / 2 0 0 1 1 1 : 1 6 : 3 2
P r 0 1
T Y P E : L E A K T E S T
C O U P L . A : 0 0 . 0 s
F I L L : 0 1. 6 s
S T A B . : 02 . 2 s
T E S T : 0 1. 5 s
D U M P : 0 1. 2 s
M a x . F I L L : 2 . 4 0
M i n . F I L L : 1 . 6 0
T e s t F A I L : 0 25
R e f . F A I L : 0 15
Note: The "PROGRAM NAME" characters are printed when a program name has been
set in the parameters.
2.4. SECURITY
This function deactivates the START and RESET keys on the instrument front panel.
Programs can only be started from the instrument inputs (J3 connector).
) Select the option and enter settings if necessary.
2.5. I/O CONFIGURATION
This menu is used to configure programmable input 7 on connector J3 on the 16-
program input/output board.
See Chapter 1, paragraph 2.2.1.1) "Connector J3 (Inputs/Outputs) programmable
input".
