ATH 7226 - Technical Data

® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-01
Manufacturer ATH-Heinl GmbH & CO.KG
- 12 -
1.4 Technical Data
Model 7226 HD
Clamping range (A)
120
–
725 mm
Rim diameter max. (B) 26 inch
Maximum wheel width (D) 780 mm
Wheel diameter max. (C) 1550 mm
Wheel weight max. 500 kg
Compression pressure /
tension
Approx. 2,000 / 3,000
kg
Mounting speed 2
Jaw chuck speed
6 / 12 rpm
Operating pressure max. 200 bar
Hydraulic motor 1.5 kW
Gearbox motor
1.8 kW
Torque 6457 Nm
Machine width (W)
1890
–
2080 mm
Machine depth (D) 1570 – 1940 mm
Machine height (H) 760 – 1240 mm
Drive voltage (3x) 400/500 V/Hz
Noise level 55 – 80 dB(A)
Weight (net)
532 kg
