Oil filler hole
Oil filler cap
NOTICE
Be sure no foreign material enters the crankcase.
9. Install the oil filler cap.
10. Close the oil filler hole.
TIP
Be sure to install securely to prevent from falling off during operation.
5.Check the oil drain, gasket, oil filler cap and O-ring. Replace them if damaged.
6. Install the oil drain bolt.
Oil drain bolt torque: 17 Nm (1.7 m·kgf, 12 ft·lbf)
7. Install the rubber cap on the buttom.
8.Add engine oil to the upper level.
Recommended engine oil:
YAMALUBE 4 (10W-40),
SAE 10W-30 or 10W-40
SAE #20
SAE 10W
Recommended engine oil grade:
API Service SE type or higher
Engine oil quantity: 0.6 L
1
2
SAE #30
3
4
31
