AIR FILTER
Securing
Screws
Remmovable
Service Panel
Air Filter
1. Remove the screws. Then remove the Remmovable service panel.
2. Remove the air cleaner cover screw. Then remove the air cleaner cover.
3. Remove the foam element.
Foam Element
Air Cleaner
Cover
Air Cleaner
Cover Screw
Air Cleaner holder
4.Wash the foam element in solvent and dry it.
WARNING
•Never use solvent while smoking or in the vicinity of an open flame.
5. Oil the foam element and squeeze out excess oil.The foam element should
be wet
but not dripping.
6. Insert the foam element into the air filter case.
7.Install the air filter cover and tighten the screws.
8.Install the cover and tighten the screws.
33
