ENGINE OIL REPLACEMENT
•Avoid draining the engine oil immediately after stopping the engine. The oil is hot
and should be handled with care to avoid burns.
Then stop the engine.
2. Remove the rubber cap on the bottom.
3. Place an oil pan under the engine Remove the oil drain bolt and gasket.
.
WARNING
WOOD BLOCKS
3.5 in (90 mm)
or greater
Place wood blocks 3.5 in (90 mm) or greater under the generator as shown.
1. Warm up the engine for several minutes.
Gasket
Oil Drain Bolt
Oil Check Access
Oil filler cap
O-ring
4.Open the oil check access as show and remove the oil filler cap so that the
oil can be completely drained.
30
rubber cap
To Next Page
