1 Description of the unit
1.1 Package
• 1 package: outdoor unit.
• 1 package: hydraulic unit and outdoor sensor.
1.2 Denitions
- Split: The heat pump consists of two elements
(an outdoor unit for outdoor and a hydraulic unit for
inside the dwelling).
- Air/water: The surrounding air is the energy source.
This energy is transmitted to the water in the heating
circuit by the heat pump.
- Inverter: the fan and compressor speeds are
modulated according to the heating requirements.
This technology enables you to save on energy and
operate on a single-phase power supply, whatever the
heat pump's output, by avoiding heavy intensities on
start-up.
- COP (coefcient of performance): this is the relationship
between the energy transmitted to the heating circuit
and electrical energy consumed.
Packing list
Heat pump (HP) Outdoor unit Hydraulic unit
Model Code Model Code Model Code
alféa extensa 5 522884
AOYA18LALL 700718
MH extensa 5-8 023155
alféa extensa 6 522885 MH extensa 6-16 023141
alféa extensa 8 522886 AOYA30LBTL 700730 MH extensa 5-8 023155
alféa extensa 10 522887 AOYA36LBTL 700736
MH extensa 6-16 023141alféa extensa 13 522658 AOYA45LBTL 700845
alféa extensa 16 522659 AOY54LJBYL 700054
Scope of application
This heat pump provides:
- Heating in winter,
- Control of two heating circuits*,
- Production of domestic hot water* (provided that
combined with a DHW tank),
- Installation with boiler connection* as a
supplementary heating for the coldest days,
or
- the addition of electrical back-ups*, for extra heating
on the coldest days,
- Cooling in summer* (for oor heating-cooling system
or fan-convectors),
- Heating the swimming pool*.
* : These options require the use of additional kits
(see para "Optional equipment").
Optional equipment
• 2nd circuit kit (code 074011)
- for connecting 2 heating circuits.
• Regulation extension kit (code 075311)
- to manage a 2nd heating circuit, swimming pool etc...
• DHW kit (réf. 073991)
- for connecting a DHW tank (with built-in electrical
back-ups).
• Boiler connection kit (code 073989)
- for connecting a boiler to the heat pump.
• Electrical back-ups kit (code 073985).
• Room thermostat T37 (code 075308),
Room thermostat T55 (code 073951)
- for correcting the ambient temperature.
• Room control unit T75 (code 073954),
Room control unit radio T78 (code 074061)
- for correcting the ambient temperature and
programming the heat pump.
• Anti-vibration blocks (code 523574).
• White PVC oor support (code 809532) or
Black rubber oor support (code 809536).
• Swimming pool kit (code 074726).
• Cooling kit (code 075312).
Installation and operating manual "1455 - EN"
Heat pump alféa extensa
