31 77900330 12
9
400
650
21
1290
147
170
196
370
99
3/8”
5/8”
Air
Overflow hole (Ø 20) 4 Ø 10)Holes
Top view
Front view
Sight of lower part
Side view
Air
Air
gure 2 - Dimensions in mm
" Outside unit,
Model extensa 13 & extensa 16
450
800
832,8
97 98
457
81
479
Heating return
ø M 26x34
Heating
ow
ø M 26x34
Front view
Side view
" Hydraulic module
gure 3 - Dimensions in mm
Installation and operating manual "1455 - EN" - 7 -
Heat pump alféa extensa
