7
DN15 copper drain lines must be connected to the discharge pipe of the
PTR valve. The copper drain line must fall away from the ESWH and be
installed in a frost- free environment.
The termination point of a drain line must comply with the requirements of
AS/NZS 3500.4
WARNING: The Pressure Temperature Relief valve and drain line must not
be sealed or blocked.
Electric Connection
All electrical work must be carried out by a registered electrician and in
accordance with AS/NZ 3000.
The Atlantic ESWH must be lled with water before connection to a power
supply.
Switch o the power before removing the cover to avoid any risk of injury or
electric shock.
The installation must be equipped, upstream of the appliance, with a
bipolar cut-out device (fuse, breaker switch) respecting local regulations
(30 mA earth-leakage breaker).
Always connect the earth conductor of the cable to the earth ground wire or
connect the earth conductor to the appropriate terminal identied by the
symbol.
Thermal cut-out
All Atlantic ESWH are equipped with a thermal cut-out with manual resetting
which shuts o the power to the water heater if it becomes overheated.
If the circuit breaker keeps tripping,
a) Switch o the power before taking any further action,
b) Remove the cover,
c) Check the electrical connections,
