Instruction book
2920 1521 00 57
2. Use the ↓ key to scroll until the option "Clock function" is followed by a horizontal arrow. Press the
tabulator key (5), following screen appears:
Clock Function
Not activated
→
Menu Modify Delete
F1 F2 F3
3. Press the tabulator key (5), following screen appears:
Monday
→
Tuesday
Wednesday
↓
Menu Delete
F1 F2 F3
4. Scroll through the display until "Saturday" is followed by a horizontal arrow. Press the tabulator
key (5). If necessary, scroll through the compressor start/stop/pressure band commands until the
command to be modified is followed by symbol ┤ on the screen. Press the key "Modify", the first
two digits of the command start blinking. Modify as required using the scroll keys, i.e. in the
example above change "18" into "17" using the ↓ key.
5. If necessary, press the tabulator key (5) to go to the next field to be modified, the minutes
indication and the start/stop/pressure band indication.
6. Press the key "Program" to program the new command or the key "Cancel" to quit without
reprogramming.
8.11.4 To add a command
Adding a command at the end of an existing list
1. Starting from the Main screen (see section 8.1.2):
- press the key "Menu" (F1)
- press the ↓ key until the option "Modify parameters" is followed by a horizontal arrow
- press the tabulator key (5) to activate the menu
2. Use the ↓ key to scroll until the option "Clock function" is followed by a horizontal arrow. Press the
tabulator key (5), following screen appears:
Clock Function
Not activated
→
Menu Modify Delete
F1 F2 F3
