8.15 Programmable settings
8.15.1 Regulation settings
Minimum
setting
Nominal
setting
Maximum
setting
Number of motor starts starts/day 240 720 720
Minimum stop time 1) sec 5 5 30
Stop between 2 compressor
modules
sec 2 2 5
Start between 2 compressor
modules
sec 2 2 10
Power recovery time 3) sec 10 10 3600
Delay at restarting after
power recovery 3)
sec 0 0 1200
Minimum pressure 2)
8 bar Pack bar(e) 4 7 7.9
8 bar Full-Feature bar(e) 4 6.8 7.7
10 bar Pack bar(e) 4 9 9.9
10 bar Full-Feature bar(e) 4 8.8 9.7
100 psi Pack bar(e) 4 7 7.9
100 psi Full-Feature bar(e) 4 6.8 7.7
125 psi Pack bar(e) 4 8.1 9
125 psi Full-Feature bar(e) 4 7.75 8.8
145 psi Pack bar(e) 4 9 9.9
145 psi Full-Feature bar(e) 4 8.8 9.7
Maximum pressure 2)
8 bar Pack bar(e) 4.1 8 8
8 bar Full-Feature bar(e) 4.1 7.8 7.8
10 bar Pack bar(e) 4.1 10 10
10 bar Full-Feature bar(e) 4.1 9.8 9.8
100 psi Pack bar(e) 4.1 8 8
100 psi Full-Feature bar(e) 4.1 7.8 7.8
125 psi Pack bar(e) 4.1 9.1 9.1
125 psi Full-Feature bar(e) 4.1 8.9 8.9
145 psi Pack bar(e) 4.1 10 10
145 psi Full-Feature bar(e) 4.1 9.8 9.8
For Full-Feature also 4)
Dewpoint warning
temperature
°C 3 15 40
Delay at signal 5) sec 0 3 10
Delay at starting 6) sec 0 255 255
