Atlas Copco BBC 16W - Page 27

Pusher legs
Piston bore
mm
(in.)
Weight
kg
(lb)
Length
extended
mm
(in.)
Length
retracted
mm
(in.)
Feeding
length
mm
(in.)
Suitable for
rock drill
Part
numberType
Single telescope
60
(2.4)
15
(33)
2958
(116.5)
1658
(65.3)
1300
(51.2)
BBC 16W/WS
BBC 34W/WS
BBC 34WTH
8321 0301 01BMT 51
70
(2.8)
14
(31)
3105
(122.2)
1805
(71.1)
1300
(51.2)
BBC 16W/WS
BBC 34W/WS
BBC 34WTH
8321 0201 94ALF 71
70
(2.8)
13
(29)
2405
(94.7)
1455
(57.3)
950
(37.4)
BBC 16W/WS
BBC 34W/WS
BBC 34WTH
8321 0201 95ALF 71-1
Double telescope
67/80
(2.6/3.1)
17
(37)
3350
(131.9)
1495
(58.9)
1855
(73)
BBC 16W/WS
BBC 34W/WS
BBC 34WTH
8321 0201 85ALF 67/80
27© 2012 Atlas Copco Construction Tools AB | No. 9800 0627 71f | 2012-06-30
Original instructions
Safety and operating instructionsBBC 16W, 16WS, 34W, 34WS, 34WTH
