10 2022 2096 26
Instruction book
Tank-mounted, vertical receiver
Tank-mounted, vertical receiver
Reference
Description
1
Compressor
2
Filter
3
Air pressure switch
4
Air receiver
5
Air pressure gauge
6
Crankcase
7
Intercooler
8
Pressure relief valve
9
Air outlet valve
10
Control panel
