3 Installation
3.1 Installation instruction
Install the unit in an area where the noise levels do not cause inconvenience and adequate ventilation is
available for cooling purposes.
Before commencing installation, check that the electrical data on the compressor
specification plate/s are compatible with the local power supply. Before connecting
the electricity, ensure that the power supply is off and correctly isolated.
The electrical power supplied to the compressor unit must be connected by a
qualified electrician in accordance with the wiring diagram supplied with the plant.
All wiring must be in accordance with UL regulations. Cable sizes given in section.
Electric data are recommendations only.
Installation proposal for CR with vertical receiver
