Oil capacity l 7.8
Oil capacity US gal 2.06
Oil capacity Imp. gal 1.72
Oil capacity cu. ft. 0.28
Sound pressure level (according to ISO 2151 (2004)) dB(A) 64
9.5 Technical data Elektronikon® controller
General
Supply voltage 24 V AC /16 VA 50/60Hz (+40%/-30%)
24 V DC/0.7 A
Type of protection IP54 (front)
IP21 (back)
Ambient and temperature
conditions
IEC60068-2
• Operating temperature
range
• Storage temperature
range
• -10°C…..+60°C (14 °F .....140 °F)
• -30°C…..+70°C (-22 °F ......158 °F)
Permissible humidity Relative humidity 90%
No condensation
Noise emission IEC61000-6-3
Noise immunity IEC61000-6-2
Mounting Cabinet door
Digital outputs
Number of outputs 9 (Elektronikon® Graphic controller - p.n. 1900 5200 10 …. 1900 5200 19)
Type Relay (voltage free contacts)
Rated voltage AC 250 V AC / 10 A max.
Rated voltage DC 30 V DC / 10 A max.
Digital inputs
Number of inputs 10 (Elektronikon® Graphic controller - p.n. 1900 5200 10 …. 1900 5200 19)
Supply by controller 24 V DC
Supply protection Short circuit protected to ground
Input protection Not isolated
Instruction book
2920 7109 23 127
