Atlas Copco GA 22 VSD+ User Manual

Compressor type I
max
(1) Maximum fuse (1) I
max
(2) Maximum fuse (2)
gL/gG aR gL/gG aR
V Hz A A A A A A
GA 22 VSD+ 400 50 59.0 - 63 63.7 - 80
GA 22 VSD+ 400+N 50 59.0 - 63 63.7 - 80
GA 22 VSD+ 460 60 59.4 - 63 64.1 - 80
GA 22 VSD+ 500 50 47.2 50 - 49.7 50 -
Compressor type I
max
(1) Maximum fuse (1) I
max
(2) Maximum fuse (2)
gL/gG aR gL/gG aR
V Hz A A A A A A
GA 26 VSD+ 200 50/60 118.8 125 - 125.1 125 -
GA 26 VSD+ 230 50/60 118.7 125 _ 125.0 125 _
GA 26 VSD+ 380 60 59.5 _ 63 64.2 _ 80
GA 26 VSD+ 400 50 59.4 _ 63 64.1 _ 80
GA 26 VSD+ 400 + N 50 59.4 _ 63 64.1 _ 80
GA 26 VSD+ 460 60 59.4 _ 63 64.1 _ 80
GA 26 VSD+ 500 50 47.5 50 - 50.0 50 -
Compressor type I
max
(1) Maximum fuse (1) I
max
(2) Maximum fuse (2)
gL/gG aR gL/gG aR
V Hz A A A A A A
GA 30 VSD+ 200 50/60 144.9 160 - 152.5 160 -
GA 30 VSD+ 230 50/60 144.8 160 - 152.4 160 -
GA 30 VSD+ 380 60 72.5 - 80 78.2 - 80
GA 30 VSD+ 400 50 72.5 - 80 78.2 - 80
GA 30 VSD+ 400 + N 50 72.5 - 80 78.2 - 80
GA 30 VSD+ 460 60 72.4 - 80 76.2 - 80
GA 30 VSD+ 500 50 58.0 63 - 61.0 63 -
Compressor type I
max
(1) Maximum fuse (1) I
max
(2) Maximum fuse (2)
gL/gG aR gL/gG aR
V Hz A A A A A A
GA 37 VSD+ 200 50/60 175.4 200 - 183.1 200 -
GA 37 VSD+ 230 50/60 175.4 200 - 183.1 200 -
GA 37 VSD+ 380 60 87.7 - 100 93.4 - 100
GA 37 VSD+ 400 50 87.7 - 100 93.4 - 100
GA 37 VSD+ 400 + N 50 87.7 - 100 93.4 - 100
GA 37 VSD+ 460 60 87.7 - 100 93.4 - 100
GA 37 VSD+ 500 50 70.2 80 - 73.2 80 -
Instruction book
104 2920 7110 05
