4 Installation
4.1 Dimension drawings
Center of gravity and weight
Type L
(mm)
B
(mm)
H
(mm)
Weight
(kg)
GA 18 VSD+ 380-460V 380 390 760 367
GA 22 VSD+ 380-460V 380 390 760 363
GA 26 VSD+ 380-460V 380 390 765 373
GA 30 VSD+ 380-460V 380 390 765 376
GA 37 VSD+ 380-460V 380 390 765 376
Instruction book
52 2920 7110 05
